Model | COB-7836 | COB-9336 | COB-2536 | COB-5636 | COB-8736 | ||||||
System Parameters | Pixel Pitch (mm) | 0.78 | 0.93 | 1.25 | 1.56 | 1.87 | |||||
Pixel Configuration | True Pixel | ||||||||||
Package Type | Flip-chip COB | ||||||||||
Module Size (mm) | 300 × 168.75 | ||||||||||
Driver IC | FM6569Q | ||||||||||
Scan Mode | 1/ 54 | 1/ 54 | 1/ 120 | 1/ 108 | 1/ 90 | ||||||
Cabinet Size (mm) | 600 × 337.5 × 35.5 | ||||||||||
Display Size (mm) | 3000 × 1687.5 | ||||||||||
Overall Size with Stand (mm) | 3010 × 2408 | ||||||||||
Native Resolution | 3840 × 2160 | 3200 × 1800 | 2400 × 1350 | 1920 × 1080 | 1600 × 900 | ||||||
Audio | 2 × 15W speakers | ||||||||||
Installation Method | Mobile stand / Wall-mounted | ||||||||||
Maintenance Method | Front maintenance | ||||||||||
System Configuration | Control System | H2 | MEE410 + KT16E | MEE210 | |||||||
Operating System | Windows | Android 13 | Android 11 | ||||||||
CPU Frequency | Subject to project requirements | 2.2GHz | 1.8GHz | ||||||||
CPU Cores | 8 | 4 | |||||||||
GPU | Mail-G52 | Mail-G52 | |||||||||
RAM | LPDDR4X 8GB | LPDDR4X 4GB | |||||||||
ROM | 64G | 32G | |||||||||
Optical Parameters | White Balance Brightness | 600 nits | |||||||||
Refresh Rate | ≥3840 Hz | ||||||||||
Contrast Ratio | 20000:1 | ||||||||||
Grayscale | ≥14-bit | ||||||||||
Color Temperature | 3000–15000 K adjustable | ||||||||||
Viewing Angle (H/V) | 175° / 175° | ||||||||||
Lifespan | 200,000 hours | ||||||||||
Electrical Parameters | Input Voltage | AC 100–240V, 50/60Hz | |||||||||
Max Power Consumption | ~1200W | ~1120W | ~1120W | ~1040W | |||||||
Average Power Consumption | ~480W | ~448W | ~448W | ~416W | |||||||
Environmental Conditions | Operating Temperature / Humidity | -10°C ~ +60°C / 10%–90% RH | |||||||||
Storage Temperature / Humidity | -20°C ~ +60°C / 10%–90% RH | ||||||||||
